High Precision Flat txaj Cnc Tshuab Servo Tsav XG40W

Tshuab Paub meej Lub npe Mars-cnc Dimension (L * W * H): 2300 * 1650 * 1750mm Certification CE ISO Nyhav: 2000kg CNC los tsis CNC Certification: ISO9001, CE, SGS Qhov chaw ntawm lub hauv paus chiv keeb yuhuan-zhejiang Tom qab-muag Service muab: Kev them nyiaj yug txawv teb chaws thib peb muaj CNC lossis Tsis yog: CNC CNC Khoom npe: XG40W ...

Xa kev nug Tsham tam sim no

Muaj nuj nqi

Tshuab Paub meej

Lub npe Mars-cnc Dimension (L * W * H): 2300 * 1650 * 1750mm

Daim ntawv pov thawj CE ISO Nyhav: 2000kg

CNC los yog tsis CNC Certification: ISO9001, CE, SGS

Qhov chaw ntawm lub hauv paus chiv keeb yuhuan-zhejiang Tom qab-muag Service Muab:Kev txhawb nqa thib peb muaj nyob txawv teb chaws

CNC los yog Tsis: CNC CNCKhoom npe: XG40W

Qhov hluav taws xobCov Neeg Siv Khoom Xav Tau Nqe: Suav tus nqi zoo tshaj

Specification

Main technical parameters	UNIT	XG 40 W
Qhov siab tshaj plaws rotary txoj kab uas hla ntawm lub txaj	mm	Φ360
Maximum tig txoj kab uas hla ntawm mop	mm	Φ180
Qhov siab tshaj plaws Z mus ncig	mm	400 (Qhov zoo machining axis 300)
Qhov siab tshaj plaws X stroke	mm	480
Kev txav ceev ceev	m/min	X:15 Z:20
Txoj kab uas hla ntawm spindle qhov	mm	Φ48
Spindle lub cev muaj zog	kws	5.5 (5.5 kW servomotor)
Spindle ceev	rpm ua	200-300(Tshwj xeeb spindle unit 5000 rotation)
Cutter cheeb tsam	mm	20×20
X kev taw qhia, Z rau lub cev muaj zog torque	nm	X:6 Z:6
X rau, Z rau lub cev muaj zog		Ncaj nraim
X kev taw qhia, Z rau cov ntsia hlau bar specification		X:3210 Z:4010
X kev taw qhia, Z rau kab rail specification		X:30 Z:35
Rov ua dua qhov tseeb	mm	0.002
Positioning precision (machine precision)	mm	0.01
Caij nplooj ntoos hlav clamping specification		Φ46 Clip taub hau, M48 raj
Chuck specifications (yeem)	mm	Φ200/Φ160(8"/6")
Hydraulic teb roj lub tog raj kheej specification (Yeem)	-	536 (tuaj yeem dhau Φ36 hauv qhov bar)
Maximum stroke ntawm lub tes tsho Tail	mm	150
Taper ntawm tailstock quill	mt	NO.4
Txias dej twj tso kua mis zog	w	120
Tshuab hnyav	kg	≈2000
Tshuab qhov ntev (ntev * dav * siab)	mm	≈2150×1650×1750

Packing & Delivery

Cov ntoo muaj zog
Ntim

Lub sij hawm xa tuaj
Hauv 60 hnub

Siab Zoo CNCTshuab dhos Manufacturing Hoobkas muab Tuam Tshoj CNC tshuab

High precision flat bed cnc machine servo motor XG40W

siv machining qauv

High precision flat bed cnc machine servo motor XG40W

Tuam txhab Profile

ZHEJIANG Haochen Smart Equipment Co., Ltd. Nyob rau hauv Tuam Tshoj tus ntug dej hiav txwv sab hnub tuaj CNC tshuab cuab yeejTuam Tshoj Customized Valve Chaw tsim khoom, chaw muag khoom - Hoobkas ncaj qha lag luam Wholesale - Zhejiang Yuhuan Lub tuam txhab tau tsim los rau 15 xyoo, koom ua ke kev tshawb fawb thiab kev loj hlob, kev tsim khoom, kev muag khoom thiab kev pab cuam tom qab muag, tshwj xeeb hauv kev tsim cov high-end, high-precision, tsis siv neeg, composite series CNC tshuab cuab yeej. Muaj ntau ntau yam thiab specifications. Lub tuam txhab muaj cov cuab yeej tsim khoom siab heev thiab cov cuab yeej ntsuas, cov cuab yeej paub tab, kev tswj xyuas kev tshawb fawb, thiab muaj kev loj hlob nrog lub tuam txhab - kev paub txog, lub luag haujlwm, kev txawj ntse, cov pob txha ntawm kev coj ncaj ncees thiab cov neeg ua haujlwm.
